11K Series
The 11K series is a miniature diaphragm pump designed for gas sampling applications and, like all other pumps in the Boxer range, can be customised to meet specific requirements. The components are produced in a wide variety of materials providing compatibility with a wide range of applications.
This series is available in iron core (2 versions), and brushless DC motor options.
› Flow rate to 1.8 l/min
› Choice of iron core and brushless motors
› Choice of wetted parts
› Robust and compact design
Flow control is available in combination withPWM Flow Controller.
| Free Flow | 1.8 l/min |
| Max Pressure | +500 mbar |
| Max Vacuum | -450 mbar |
| Voltage Options | 12 V DC |
| Power Consumption | 0.96 to 1.56 W |
| Elastomers | EPDM |
| Other Wetted Parts | PBT (Polybutylene terephthalate) |
| Weight | - g |
Available, shipping in 1 - 2 days
| Free Flow | 1.6 l/min |
| Max Pressure | 500 mbar |
| Max Vacuum | -450 mbar |
| Voltage Options | 12 , 24 V DC |
| Power Consumption | 0.96 to 1.44 W |
| Elastomers | EPDM |
| Other Wetted Parts | PBT (Polybutylene terephthalate) |
| Weight | 54 g |
Available, shipping in 1 - 2 days
Available, shipping in 1 - 2 days
| Free Flow | 1.8 l/min |
| Max Pressure | 500 mbar |
| Max Vacuum | -450 mbar |
| Voltage Options | 12 to 24 V DC |
| Power Consumption | 1.56 to 2.88 W |
| Elastomer | EPDM |
| Other Wetted Parts | PBT (Polybutylene terephthalate) |
| Weight | 72 g |
Available, shipping in 1 - 2 days
